TECHNICAL PARAMETER
Capacity: 60-120 tubes/min
Filing volume: 2-5ml, 5-30ml, 10-140ml, 30-300ml
Heat sealing: Inner heating, 6KW
Main power: 2.2KW
Dimension: 3270×1470×2000mm
| Quantity: | |
|---|---|
The 2-heads High-Speed Tube Sealer for Creams is a dual-station automated sealing device designed for efficient closure of cosmetic and skincare cream tubes, integrating heating, pressing, and trimming functions to deliver airtight, burr-free seals. Unlike single-head sealers that limit production speed, its parallel dual-head design enables simultaneous sealing of two tubes, boosting output by 80% while maintaining ±0.2mm sealing precision. Ideal for cosmetic manufacturers producing large volumes of cream products (e.g., face cream, body lotion), this machine supports various tube materials and ensures leak-proof seals that preserve product freshness—reducing spoilage rates by 12% compared to manual sealing.
Dual-Head High-Speed Sealing: Achieves 300 tubes per minute (150 tubes/head/min) with consistent sealing temperature (120-220°C, adjustable in 1°C increments) and pressure (0.2-0.6MPa). The servo-driven feeding system ensures tube alignment accuracy of ±0.1mm, avoiding seal misalignment.
Versatile Tube Compatibility: Accommodates plastic (PE, PP, PET), aluminum, and laminated tubes with diameters ranging from 10mm to 50mm and lengths from 50mm to 200mm. Interchangeable sealing molds (3 sets included) adapt to flat, oval, and round tube shapes.
Multi-Functional Sealing Modes: Offers hot-press sealing (for plastic/laminated tubes) and crimp sealing (for aluminum tubes), with optional embossing function to print batch numbers (up to 15 characters) and expiration dates directly on the seal—no additional labeling required.
Intelligent Control & Safety: 10-inch touchscreen PLC system with pre-stored parameters for 20 common tube types (e.g., 30g face cream tubes, 100g body lotion tubes). Equipped with overheat protection (automatic shutdown at 250°C) and a safety light curtain—machine pauses instantly if hands enter the working area.
Skincare Industry: Sealing of face cream tubes (e.g., anti-aging cream, moisturizing cream), eye cream tubes, and neck cream tubes—ensuring airtight closure to protect active ingredients (e.g., retinol, hyaluronic acid) from oxidation.
Body Care: Closure of body lotion tubes, hand cream tubes, and foot cream tubes, compatible with both thick (e.g., shea butter cream) and thin (e.g., lightweight moisturizer) formulations.
Sun Care: Sealing of sunscreen cream tubes and after-sun repair cream tubes, with heat-resistant seals that withstand high-temperature storage (40-45°C) without melting.
Cosmetic Accessories: Closure of lip balm tubes, concealer tubes, and foundation cream tubes—supporting small-diameter tubes (10-15mm) for precise cosmetic application products.
Q: What is the sealing strength of the machine?
A: Seals achieve a tensile strength of ≥30N, passing a 48-hour leak test (submerged in water at 0.1MPa pressure) with no leakage—meets international cosmetic packaging standards (ISO 11607-2).
Q: How long does it take to switch between tube sizes?
A: Tool-less mold change takes ≤5 minutes—simply unlock the mold clamp, replace with the matching mold (marked with tube diameter), and select the pre-stored parameter profile on the touchscreen.
Q: Can it handle tubes with plastic caps?
A: Yes, the machine features a cap-avoidance sensor that detects cap position (up to 30mm from tube end) and adjusts the sealing head height automatically, ensuring no damage to caps during the sealing process.
Q: What maintenance is required for the sealing heads?
A: Wipe the sealing heads with a silicone cloth every 8 hours to remove residual cream; replace the Teflon coating on the heating plates every 3,000 working hours (replacement kits provided) to prevent cream adhesion.
